4 Banger LED Light Pods: NCS Spot Beam (BAF001)

Introducing the Morimoto 4Banger NCS Off-Road LED Lights – a game-changer in automotive lighting! Since 2008, Morimoto has been synonymous with performance, reliability, and style, and our new 4Banger NCS lives up to that legacy. Designed, engineered, and tested in the USA, these lights redefine off-road illumination. With a focused 5-degree hot spot and a 14H x 4C degree flood beam, the NCS Spot Beam ensures unrivaled long-range visibility. Plus, it’s 30% smaller than alternatives for that perfect fit. Morimoto’s proprietary technology, including Nichia LEDs and optimized thermal dynamics, guarantees top-tier performance. Whatever the weather, choose between white or yellow output for optimal visibility. And rest easy knowing that the 4Banger is built to last with IP69K weather resistance and a durable aluminum shell. Upgrade your vehicle with the Morimoto 4Banger NCS and experience off-road reinvented. Don’t miss out on this next-level lighting solution!

What’s Included:

• LED Pods: 2x (One Pair) Morimoto 4Banger NCS Spot (White or Yellow)

• Brackets: 2x (One Pair) Universal U-Shape Mounts

• Hardware: Complete pack (stainless steel)

• Optional Wiring: 1x Morimoto Switched Relay Harness or 2x Deutsch DT Pigtails available separate

• Optional Covers: 2x Rubber Blackout Covers available separate

Features:

• Exceptional Visibility: 5-degree hot spot and flood beam for long-range visibility.
• Compact Design: 30% smaller for sleek OEM+ fitment with mounting kits.
• Proprietary Performance: Optimized for modern LEDs from Nichia.
• All-Weather Reliability: Meets IP69K standards for weather resistance.
• USA Engineering: Designed, engineered, and tested in the USA for top-tier performance and style.

Specs:

• Intensity (White): 105,000 Cd (Post Warm-Up) (1,005lux @ 10m)

• Intensity (Yellow): 73,500 Cd (Post Warm-Up) (735lux @ 10m)

• Input: Proprietary Overmolded Deutsch DT 2-Pin w/ Pigtail

• Power (stabilized): 15.6w

• Current: 1.5A @ 13.5V DC

• Peak Luminosity (raw): 1,350lm

• Dimensions: 82mm W, 67mm H, 60mm D

• Hardware: M6 x 1.0 x 8mm (4Banger to U-Bracket), M10 x 1.5 x 20mm (U-Bracket base)

• Light Source: 3x Nichia NCSY131F or NCSW131F

• Material: Makrolon LED PC (Lens), Powdercoated Die Cast Aluminum (Housing)
